 BK7 optical amici prism
详细信息 The general tolerance specifications above provide a guideline regarding manufacturing capabilities for optics ranging in size from 3-76.2mm. The manufacturing limits are not absolute;tighter tolerances may be possible. Part specific tolerances may vary depending on ponent size, shape, and/or material.
Specification of our amici prism as follow:
*Material BK7 or UV grade fused silica
*Dimension Tolerances +/-0.1mm
*Clear Aperture >80%
*Surface Quality:60/40 Scratch/Dig
*Surface Flatness lambda/4 at 633nm
*Angle Tolerance 60 degree+/-3 minutes
*Chamfer 0.3mm+/-0.1mm m
*Coatings Optional |
